The newest YT-2401 2D Wireless Bluetooth Barcode scanner/Bar Code Reader android IOS handheld barcode scannerThe newest YT-2401 2D Wireless Bluetooth Barcode scanner/Bar Code Reader android IOS handheld barcode scannerThe newest YT-2401 2D Wireless Bluetooth Barcode scanner/Bar Code Reader android IOS handheld barcode scannerThe newest YT-2401 2D Wireless Bluetooth Barcode scanner/Bar Code Reader android IOS handheld barcode scannerThe newest YT-2401 2D Wireless Bluetooth Barcode scanner/Bar Code Reader android IOS handheld barcode scannerThe newest YT-2401 2D Wireless Bluetooth Barcode scanner/Bar Code Reader android IOS handheld barcode scannerThe newest YT-2401 2D Wireless Bluetooth Barcode scanner/Bar Code Reader android IOS handheld barcode scannerThe newest YT-2401 2D Wireless Bluetooth Barcode scanner/Bar Code Reader android IOS handheld barcode scanner

The newest YT-2401 2D Wireless Bluetooth Barcode scanner/Bar Code Reader android IOS handheld barcode scanner

  • Scan Element Type: CMOS
  • Colour Depth: 32 Bit
  • Interface Type: USB
  • Optical Resolution: 4mil
  • Scan Speed: 300times/second
  • Brand Name: Yumite
  • Model Number: YT-2401
  • Wireless Transmitting
  • Distance: 15 - 20M
  • Optical Source: 650nm Visible red light diode
  • Reading Precision: ≥ 4mil Minimum
  • Contrast: ≥ 30% Data
  • interface: RJ-45
  • Weight: 155g
  • Indicator: Siren and LED light
  • Height Range: 1.5M
  • Charging Current: 450ma
  • IP Rating:IP52
Model YT-2401   2D Bluetooth Barcode Scanner
Performance Parameter
Wireless Transmitting Distance(Without Barrier) 15 - 20M
Optical Source 620nm Visible red light diode
Imaging Sensor CMOS
Image Resolution 752×480Pixel
Reading Precision ≥ 5mil
Reading Depth Code 39 40mm -280mm(10mil); 85mm~325mm(15mil)
PDF417 60mm -225mm(10mil); 60mm~340mm(15mil)
Data Matrix 20mm -155mm(10mil); 35mm~235mm(15mil)
QR Code 35mm -150mm(10mil); 20mm~230mm(15mil)
Minimum Contrast ≥ 30%
Decoding
Capacity 2D PDF417, QR Code(Model 1/2),
Data Matrix(ECC200, ECC000,050, 080, 100,140)
1D Code 128, EAN-13, EAN-8, Code 39, UPC-A, UPC-E, Codabar,
Interleaved 2 of 5, ISBN, Code 93, UCC/EAN-128, GS1 Databar, etc.
Decoding Speed 300times/second
Barcode
Sensitivity Tilt ±55°
Rotate ±25°
Deflection ±75°
Data Interface RJ-45
Mechanical and Electric Performance
Size(Length x Width x Height) 92.5×70×154.6 mm
Weight 155g
Indicator Siren and LED light
Battery Capacity 600Mah
Max.Power 1092mw
Working Voltage DC5V
Current Max.Current 262ma
Working Current 325ma
Standbu Current 53ma
Charging Current 450ma
Accessory List
Data Cable USB
Wireless Receiver 1
CD 1
Operation Manual 1
Environmental Parameter
Storage Temperature -40°C ~ 60°C
Working Temperature 0°C ~ 50°C
Relative Humidity 0 ~ 95%
Height Range 2M
IP Rating IP52

Certificates:

CE,RoHS,EMC,LVD,ISO9001:2008,ISO14001:2004
